Diaphragm pump in aluminum with cataphoresis treatment series AABM-2 modular with 2" flanges, membranes and balls in Teflon® and seats in polypropylene
Flow rate | 550 l/min |
Ratio | 1:1 |
Max pressure | 8 bar |
Max cicles for minute | 147 cpm |
Delivery for cicles | 3,950 l |
Max suction lift | dry column 5 m - wet column 7,5 m |
Max size pumpable solids | 6,5 mm |
Max working temperature | 65 °C |
Noise level | 82 dB |
Max air consumption | 4,00 m3/min |
Air working pressure | 2 ÷ 6 bar |
Air inlet connection | G 3/4" (f) |
Air outlet connection (muffler) | G 1" (f) |
Fluid inlet connection | ANSI 150 - DIN PN 10 - JIS 10K 2" (50 mm) |
Fluid outlet connection | ANSI 150 - DIN PN 10 - JIS 10K 2" (50 mm) |
Balls for inlet | ball valve |
Membranes | PTFE+Hytrel® |
Balls | PTFE |
Seats | polypropylene |
Packing | No. 1 - 0,13 m3 |
Gross weight | 50 kg |
